Home > Product > Cabinet Air Conditioner > Horizontal Mounted Cabinet Air Conditioner

Horizontal Mounted Cabinet Air Conditioner

JH-JGH

Cooling Capacity: 320W~630W

  • Easy operating，high efficiency and energy saving.
  • Intelligent multi-protection function of Over temp alarm, Overload alarm, Self-diagnosis, Intelligent antifreeze, Flow alarm, Water level alarm, Pressure Alarm, etc.
  • Long service life with stable performance.
Download Contact Us
Horizontal Mounted Cabinet Air Conditioner
Model JH-JGH-320 JH-JGH-450 JH-JGH-630
Item
Cooling capacity W 320 450 630
Btu/Hr 1092 1536 2150
Cabinet temp. limits ℃ 15-40 15-40 15-40
Ambient temp. limits ℃ 15-55 15-55 15-55
Circuit max. pressure bar 26 26 26
Power supply V/Ph/Hz 220/1/50 220/1/50 220/1/50
Rated current A 1.2 1.4 1.6
Input power W 245 290 350
Cabinet air flow m3/h 165 240 320
Ambient air flow m3/h 325 450 575
Refrigerant R134a R134a R134a
Cabinet protection ration IP54 IP54 IP54
Ambient protection ration IP30 IP30 IP30
Noise level dB(A) 55 56 58
Weight kg 14 18 22
Dimension H mm 290 290 290
W mm 520 520 520
D mm 220 220 220
The above cooling capacity is based on the ambient temperature 35℃, the cabinet internal temperature 30℃.
  • Brand quality raw materials
  • Advanced production equipment and technology
  • Own R&D team assure the premium stable quality and technical support
  • Full range product assortments for your choice
  • Customized solutions supported

Core Value

Hundreds of models

Importd Brand Compressor

Excellent quality, provide lasting power!

Stainless steel tube evaporator

Stainless steel shell, industrial grade internal thread copper pipe, no "leakage" can be hit!

Touch screen controller

5 "color screen, dynamic display, detached experience

High efficiency low noise fan

Excellent performance, adapt to a variety of complex environment

Copper tube condenser with internal thread

Trapezoidal internal thread structure, efficiency increase by 30%

Brand Electrical Components

Electrical components are famous brands, reliable quality!

Multiple Protection

Overtemperature protection

Current protection

Self diagnosis

Intelligent antifreeze

Water flow alarm

Water level alarm

Pressure alarm

Time switching machine

Intelligent control

The data changes in a second

Color touch screen 5 inches HD true color touch screen, touch sensitive. Simple and fast operation, dynamic display unit operation!

Dynamic monitoring allows "no escape from failure"

Dynamic monitoring operation automatically displays the compressor, water pump and other working conditions, the unit state at a glance, all in control.

A "week by week" schedule relaxes your management

Cycle timing function Cycle timing function can operate the temperature pipeline effectively, and the unit start and stop time can be set freely within a week.

Intelligent anti-freezing can also operate in winter, such as "flying"

Intelligent antifreeze function When the water temperature is low, the unit automatically enters the antifreeze mode, no need to worry about the unit freezing!

Self-diagnosis is more than sweet

Self-diagnosis powerful self-diagnosis function, so that you easilly diagnose the fault.

That's how stable condensation control is

Condensation temperature control Intelligent control of condensing temperature, hight efficiency and energy saving, to ensure the compressor continuous and stable work.

Perfect Detail
  • Danfoss expansion valve
  • Each pipe fitting is made of stainless steel
  • Each circuit is clearly classified
  • Every piece of sheet metal is itted together
  • All solider joints are cleaned
  • Stainless steel water pump
  • Brand Electrical Components
  • Danfoss drying filter



  • Scientific Research.
  • Automobile Industry.
  • Food & Drinks Industry.
  • Paper & Printing Industry.
  • Heavy Machinery Industry.
  • Plastic & Rubber Industry.
  • Electronic & Chip Industry.
  • Chemical & Pharmaceutical Industry.
